A328

Jensen A328 – 9” x 11” Wood Chipper

The Jensen A328 Diesel is a heavy-duty professional wood chipper with a generous 230mm x 280mm (9” x 11”) infeed, making it ideal for arborists and contractors who regularly handle large, awkward, or bulky material. Powered by a high-torque diesel engine, it combines exceptional capacity with the efficiency and reliability Jensen is known for.

Available in tracked, trailed, or PTO-driven configurations, the A328 offers versatility for a wide range of work environments — from tight urban sites to rough terrain. Its twin hydraulic feed rollers, aggressive intake, and optimised cutting disc design ensure smooth processing of forked, twisted, and leafy branches without constant reversing.

The 9” x 11” capacity sets it apart from smaller chippers, while its compact design compared to the larger A550 makes it a strong choice for crews who want big capability without the footprint of a full 10” machine.

Key benefits:
9” x 11” oversize capacity for bulky material
Tracked, Trailed, or PTO options for site flexibility
Robust German engineering with NZ-based support
Designed for high-output professional use
Jensen A328 – big capacity, built for serious work.

Tracked

Trailed

PTO

Turntable

Power Control System

Galvanized Chassis

Chute 360° Rotatable

Central Greasing Point

Automatic V-belt Tensioner

Electronic Controlled Sensor Buttons

114 dB LWA

  • - 70 HP Kubota Diesel Engine
    - 2 Blades
    - 9" x 11" chipping capacity with double inter-meshed feed rollers for maximum infeed pull
    - Oversized top roller
    - 12/24 Volt LED Lights with Light Guards
    - Spare Wheel Mounting Bracket
    - 2 Wheeled Brake + Hand brake
    - Custom designed draw bar and chute to fit the desired tow vehicle
    - Central Grease Bank
    - Fully Galvanized Chassis

  • Max. Capacity: 9" (220 mm)
    Feed roller aperture: 9" x 11"
    Engine: Kubota
    Output: 70 HP
    Diameter flywheel: 820 mm
    Thickness flywheel: 35 mm
    RPM flywheel: 1.000 RPM
    Chip size: 5 - 20 mm (hydr.adjustable)
    Infeed: Hydraulic motor/gear box
    Hopper (WxH): 1.150 x 800 mm
    Hydraulic tank: 23 L
    Chassis: 80 km/h (single axle/tandem)
    Tyres: 185/65R14 or 205R14C
    Fuel tank capacity: 70 L
    Dimensions (LxW) 4.100 x 2.140 mm
    Working height: 850 mm
    Transport Height: 3.000 mm
    Weight: approx. 2.100 kg
    Turntable: Yes
    Capacity: approx. 25 m3/h
